Pilt on illustreeriv
|
Hargnemisklemm Al/Cu UK240/3N, 1P (6holes) 35-240mm² 760/850A 1000VAC/ 1500VDC, Hex8 26Nm 35..120mm²/ 46Nm 150..240mm², panel mount, MaxPro, sinine Kood:
1914310
Hind
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.875 kg/tk
|
Maht:
0.0015 m3/tk
|
|
|
|
|
| |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
grey |
| Wire mm²: |
35-240 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
8 mm |
| Nominal Rated Current A: |
Cu 1275 A, Al 1140 A |
| Number of poles: |
1 |
| Standard: |
SFS 2663 |
| Nominal Tightening Torque Nm: |
14 Nm (25-50mm²)
25 Nm (50-120mm²)
30 Nm (70-150mm²) |
|
|
|
