Hargnemisklemm UK50/3x1A, 3P (2ava) 2.5-50mm² 145/160A 750V, TS35, MaxPRO, hall Kood:
1914109
Hind
|
Saadavus:
Laos
|
Kaal:
0.1054 kg/tk
|
Maht:
0.0002 m3/tk
|
Hulgipakendi kogus:
5tk
|
|
|
|
Terminal Block Al/Cu 3x(2,5-50)mm2, grey
 |
|
| Name: |
Terminal Block Al/Cu 3x(2,5-50)mm2, grey |
| Colour: |
Grey |
| Housing: |
polyamide |
| Mounting: |
DIN rail |
| Screw head: |
hexagon |
| Pollution degree: |
3 |
| Operating temperature (°C): |
Max 80 °C |
| Conductor cross-section mm2: |
Cu 2,5-50 mm2 Al 6-50 mm2 |
| Conductor size (AWG): |
1/0-6 |
| Number of poles: |
3 |
| Weight (kg): |
0,077 |
| Nominal current A: |
Cu 480 A, Al 435 A |
| Nominal insulation voltage V: |
690 V |
| Screw head size: |
5 mm |
| Standard: |
EN 61238-1, EN 60947-7-1, UL 1059 |
| Connector class: |
A |
| UL category: |
XCFR2 |
| UL File no.: |
E192532 |
| Tightening torque Nm: |
4 Nm (2.5-4mm2), 12 Nm (6-50mm2) |
| Tightening torque Lb-In (US): |
90 Lb-In |
|
|
|
