Pilt on illustreeriv

Hargnemisklemm UK50/2PE, 1P (4ava) 2.5-50mm² 145/160A, TS35, MaxPRO, MaxPRO, koro

Kood: 1914108

Hind

€ 6,10 /tk

Saadavus:

Laos

Kaal:

0.0683 kg/tk

Maht:

0.0001 m3/tk

Hulgipakendi kogus:

6tk

Terminal Block Al/Cu 3x2,5-50mm², grey

Name	Terminal Block Al/Cu 3x2,5-50mm², yegr
Working temperature (ºC):	max 80ºC
Housing:	polyamide
Fastening:	DIN-rail
Screw head:	hexagon
Colour:	yegr
Wire mm²:	Cu 2,5-50 mm² Al 6-50 mm²
Nominal Insulation Voltage V:	800 V
Screw head size:	5 mm
Nominal Rated Current A:	Cu 320 A, Al 290 A
Number of poles:	1
Standard:	EN 61238-1, EN 60947-7-1
Nominal Tightening Torque Nm:	4 Nm (2.5-4mm²), 12 Nm (6-50mm²)
